GPU & Core Specifications
The ZOTAC Gaming GeForce RTX 5060 Twin Edge is powered by the NVIDIA GeForce RTX 5060 GPU, designed for next-generation gaming and creative workloads. It features 3,840 CUDA cores and achieves a boost clock speed of 2497 MHz, ensuring high performance across demanding titles and applications. With support for Microsoft DirectX 12 Ultimate and OpenGL 4.6, it enables advanced ray tracing, AI-driven rendering, and future-ready graphical capabilities.

Memory & Interface
This card comes equipped with 8GB of GDDR7 video memory, delivering cutting-edge speed and efficiency. The 128-bit memory bus and 28 Gbps memory clock provide excellent bandwidth, ensuring smooth performance even in high-resolution and resource-heavy scenarios. The GPU connects via PCI Express 5.0 x8, ensuring ultra-fast data transfer between the graphics card and system.

Display & Connectivity
The RTX 5060 Twin Edge supports up to quad display output, making it ideal for multi-monitor setups. It features three DisplayPort 2.1b connectors with UHBR20, supporting resolutions up to 4K at 480Hz or 8K at 165Hz with DSC. Additionally, it includes one HDMI 2.1b connector, capable of 4K at 480Hz HDR or 8K at 120Hz HDR with DSC, along with Gaming Variable Refresh Rate (VRR) support. HDCP 2.3 ensures compatibility with protected content streaming.

Cooling & Form Factor
The Twin Edge utilizes an advanced air-cooled thermal system that keeps the GPU running at optimal temperatures, even under heavy load. It adopts a dual-slot design with dimensions of 220.5mm x 120.25mm x 41.6mm (8.7" x 4.7" x 1.6"), offering a balance between performance cooling and compact build compatibility.

Power & System Requirements
With a power consumption of 145W, the card requires a recommended 550W power supply for stable operation. It draws power via a single 8-pin power connector, ensuring efficient energy delivery. The GPU is compatible with Windows 11 and Windows 10 (64-bit, version 1809 November 2018 or later).

Included Accessories
Inside the package, the card comes with a user manual to guide installation and setup.
