DaVinci Resolve Advanced Panel – Technical Specifications

Connections

The DaVinci Resolve Advanced Panel features a USB Type-B connector on each panel for direct computer connection. For panel-to-panel connectivity, it offers 2 loop-out USB Type-A connectors on the side panels. An integrated USB Hub with two USB Type-A ports allows connection of peripherals such as a mouse or other USB devices. Each panel is also equipped with USB Type Mini-B connectors for factory software updates.

Power Connectivity

The Trackball Panel features a 12V Power Input via a centre 3-pin 3W3 D-Sub connector. The Search Dial and T-bar Panels also include 3-pin 3W3 D-Sub power connectors. Additionally, the Trackball Panel provides left and right 12V Power Outputs via 3-pin 3W3 D-Sub connectors for daisy-chaining power to other panels.

Power Requirements

The panel operates with an external 100 - 240V AC, 1.5A, 50/60Hz power supply featuring an IEC C14 mains input. Maximum power usage is 80W.

Operating System Compatibility

The DaVinci Resolve Advanced Panel is compatible with Mac systems running macOS 13.0 Ventura or macOS 14.0 Sonoma and later. For Windows, it supports Windows 10 Creators Update and Windows 11. It also supports Rocky Linux 8.6 for professional workflows.

Environmental Specifications

The unit operates optimally at temperatures from 0° to 40°C (32° to 104°F) and can be stored between -20° to 60°C (-4° to 140°F). It supports 0% to 90% non-condensing relative humidity for reliable use in diverse environments.

Package Contents

The package includes the DaVinci Resolve Advanced Trackball Panel, Advanced Search Dial Panel, and Advanced T-bar Panel, along with a DaVinci Resolve Advanced Panel Dongle and a DaVinci Resolve Studio Activation Key. Also included are a 12V Power Supply with IEC C14 mains inlet, two 1m 3-pin Inter Panel Power Cables, and three 2m USB Type-A to Type-B cables.

Warranty

The DaVinci Resolve Advanced Panel comes with a 1-Year Limited Manufacturer’s Warranty for peace of mind and reliable performance.
