Blackmagic Cloud Store 80TB – Technical Specification

Key Specifications

The Blackmagic Cloud Store 80TB offers an immense 80TB of high-speed NVMe M.2 flash storage, configured in a RAID 5 setup to ensure both speed and data redundancy. It is designed to meet the needs of professional film, post-production, and VFX teams who demand fast, reliable access to large media files.

Drive Configuration

Equipped with a single 80TB SSD array, the internal architecture is optimized for performance and reliability. The RAID 5 configuration balances redundancy with high read/write speeds, making it suitable for demanding workflows such as editing high-resolution RAW files and real-time collaboration.

Inputs and Outputs

The unit features 4 x RJ45 10GbE ports, ensuring ultra-fast connectivity across multiple users. Additionally, it includes 2 x RJ45 Gigabit Ethernet ports for broader compatibility, and 2 x USB-C 3.0/3.1/3.2 Gen 1 ports (one input and one output) to support data transfer and configuration. A dedicated HDMI output allows real-time monitoring of system status.

🌐 Networking and Redundancy

Blackmagic Cloud Store 80TB supports link aggregation and failover to ensure network reliability and uninterrupted performance. It is built to handle the needs of large teams working on simultaneous high-bandwidth tasks without performance drops.

Software Compatibility

This system supports Windows 10 to 11 and macOS 11.1 or later, and it is also compatible with Android and iOS mobile applications. Users can easily manage and configure the device using the included Blackmagic Cloud Setup Utility.

Security

While the Cloud Store 80TB does not feature built-in encryption or advanced security protocols, it is designed for secure environments where access control is managed externally through network firewalls and user permissions.

Power & Electrical

The device operates on an input power of 100 to 240 VAC at 50/60 Hz. It comes with dual redundant power supplies (PSUs), ensuring continuous uptime in critical environments. The maximum power consumption is rated at 400W.

Environmental Conditions

The operational temperature ranges from 0° to 40°C (32° to 104°F) with humidity support up to 90% non-condensing. It can be stored safely at temperatures between -20° to 60°C (-4° to 140°F).

Physical Dimensions and Packaging

Compact and rack-friendly, the unit measures 11.6 x 7 x 7 inches (29.5 x 17.8 x 17.8 cm) and weighs approximately 13.2 lbs (6.0 kg). It is shipped in secure packaging with a total box weight of 17.05 lbs and dimensions of 17.3 x 10.5 x 10.3 inches.
