The Atem Mini Pro (ATEM Mini Extreme ISO G2) is a professional live production switcher designed for broadcasters, streamers, and creators who need powerful multi-camera workflows with advanced audio and video control. It features a wide range of inputs, outputs, and processing capabilities that make it ideal for high-end live productions, streaming, and recording.

Connections

The switcher includes a total of 9 video inputs, consisting of 8 HDMI Type-A ports supporting 10-bit HD video with 2-channel embedded audio, and additional input routing via USB and Thunderbolt. It provides 4 total outputs, including 3 HDMI outputs and 1 multi-view output that can be routed to HDMI, USB-C, or Thunderbolt connections. For audio, it offers 2 XLR combo inputs with phantom power and 1 BNC MADI connection supporting 32 channels of digital audio, along with a 6.35 mm headphone jack for monitoring.

Video and Signal Support

The Atem Mini Pro supports SDI rates of 1.5G and 3G, along with extensive HDMI video input compatibility. Input re-synchronization and real-time format converters are available on all HDMI and remote sources, ensuring smooth integration of multiple devices. The unit supports frame rates up to 1080p60 with HD standards including 720p50/59.94/60, 1080p23.98 to 60, and 1080i50/59.94/60. Output standards include 1080p at up to 60fps, with streaming and recording supported at the same frame rates. Video sampling is 4:2:2 YUV, with 10-bit precision and Rec. 709 color space.

Control and Switching

The switcher is equipped with 1 mix-effects row and 10 direct cross points using high-quality NKK buttons. It offers 6 dedicated macro buttons, 8 key buttons, 6 DSK transition selectors, and a fade-to-black NKK button, providing flexible live switching options. Users can take advantage of 4 upstream keyers, 2 downstream keyers, 4 advanced chroma keyers, 2 DVEs, and a SuperSource layout with up to 16 routable windows for advanced live compositions. A tactile fader bar and multiple transition options ensure professional-grade control during production.

Audio Features

The built-in 26 x 2 channel Fairlight audio mixer integrates audio from HDMI, XLR, MADI, and Thunderbolt sources. It supports compressors, limiters, gates, and 6-band parametric EQ per channel, with full master gain control and peak metering. Phantom power (+48V) is available on XLR inputs, and analog delay compensation of up to 8 frames is supported. For recording, the switcher captures 26 x 2 channel audio inputs as separate 24-bit 48kHz WAV files, ensuring high-fidelity sound in live and post-production.

Streaming and Recording

The Atem Mini Pro supports direct streaming via RTMP and SRT protocols over Ethernet or USB-C internet sharing. It can stream directly to platforms such as YouTube, Facebook, and custom RTMP servers. For recording, it provides CFExpress, USB-C external recording, and network-based storage options. Each HDMI input can be recorded as a separate ISO file in H.264 MP4 format at up to 70Mbps, alongside program output and individual audio tracks. Additionally, switching data is saved as a DaVinci Resolve .drp project, allowing editors to relink and re-edit live productions seamlessly.

Multi-View and Media Players

The switcher features a configurable multi-view system with layouts supporting 16, 13, 10, 7, or 4 views, displaying program, preview, HDMI inputs, SuperSource, clean feeds, media players, and audio meters. Two integrated media players provide fill and key channels, with a media pool capacity of 20 still images and up to 200 frames of 1080 HD video. Supported formats include PNG, TGA, BMP, GIF, JPEG, TIFF, WAV, MP3, and AIFF.

Control and Software

The Atem Mini Pro includes a built-in control panel and supports optional hardware panels such as the ATEM 1 M/E and 2 M/E Advanced Panels. It is fully compatible with ATEM Software Control for macOS (Sonoma 14 / Sequoia 15 or later) and Windows 10/11, offering complete remote configuration and switching. Updates and setup are managed through Ethernet or USB-C connections. The switcher also integrates seamlessly with Blackmagic Design cameras, offering control over focus, iris, zoom, color correction, tally, and recording functions.

Power and Physical Specifications

The unit requires a 12V external power supply, with maximum consumption of 120W. It operates reliably in temperatures from 5° to 40°C (41° – 104°F), can be stored between -10° and 60°C (14° – 140°F), and functions in humidity levels from 0% to 90% non-condensing.

Package and Warranty

Included in the package is the ATEM Mini Extreme ISO G2 switcher, along with an external 12V DC power supply. The product comes with a 1-year limited manufacturer’s warranty.
