ATEM 2 M/E Advanced Panel 40 Technical Specifications

Connections

The ATEM 2 M/E Advanced Panel 40 offers robust connectivity with four 10/100/1000 BASE-T Ethernet ports featuring loop output, allowing connection to additional control panels or computers. A dedicated USB-C port is available for firmware updates, ensuring the panel stays up to date with the latest features and performance improvements.

Product Specifics
This professional control panel includes 2 mix effects (M/E) rows, 40 direct cross points, and 80 shifted cross points for flexible switching capabilities. It features tri-color LED crosspoint buttons and a 6-row, 24-character LCD for clear labeling. The panel includes 12 on-air indicators, 4 DSK transition selectors (Auto, Cut, Tie/Preview), and 2 preview transition controls. It also offers 4 LCD menu displays with 4 x 20 menu control buttons, 2 sets of 40 dedicated macro buttons, and 8 transport control buttons. Additional controls include 2 destination buses, 2 source select buses, dual fader bars, a 3-axis joystick, and a numeric keypad.

Software
The ATEM 2 M/E Advanced Panel 40 is compatible with the ATEM Software Control Panel application, offering extended functionality and remote operation.

Operating Systems
The panel supports macOS 14.0 Sonoma and macOS 15.0 Sequoia or later, as well as Windows 10 and Windows 11.

Power Requirements
It operates on dual internal 100-240V AC inputs for worldwide voltage compatibility and includes redundant power for uninterrupted performance. Power usage is rated at 160W.

Environmental Specifications
The ATEM 2 M/E Advanced Panel 40 operates reliably in temperatures ranging from 0° to 40°C (32° to 104°F) and can be stored in temperatures from -20° to 60°C (-4° to 140°F). It supports up to 95% relative humidity, non-condensing.

What's Included

• ATEM 2 M/E Advanced Panel 40

• Welcome wallet with QR code for software download

Warranty
The product is backed by a 1-Year Limited Manufacturer’s Warranty.
