Connections

The ATEM 1 M/E Advanced Panel 10 is equipped with two Ethernet ports supporting 10/100/1000 BaseT. These include a loop output that allows connection to additional control panels or computers for flexible system setups. For firmware updates, the panel also includes one USB-C port, ensuring easy and efficient software maintenance.

Product Specifics

This panel provides 10 direct cross points and up to 20 shifted cross points, offering comprehensive switching control. The crosspoint buttons feature Tri-Color LED indicators and are supported with a 3-row, 24-character LCD label display, delivering clear and accurate labeling. It includes 4 On-Air indicators, while transition controls are enabled through selectors for Auto, Cut, and Tie/Preview functions. A single Preview Transition option and transition rate display via the main menu ensure precise operation.

The panel is built with 3 LCD menu displays and 20 dedicated menu control buttons for intuitive operation. It also comes with 10 dedicated macro buttons, a fader bar, and a 3-axis joystick for advanced transition and DVE control. Additionally, a numeric keypad is integrated for quick and accurate parameter entry.

Software

The panel is fully compatible with the ATEM Software Control Panel, providing extended configuration and operational options. It supports both Mac (macOS Sonoma 14.0, Sequoia 15.0 or later) and Windows (Windows 10 and 11) operating systems, ensuring broad integration flexibility.

Power Requirements

The ATEM 1 M/E Advanced Panel 10 operates on an internal 100 – 240V AC input voltage, making it suitable for global use. It features redundant power support for uninterrupted operation in critical production environments. The device consumes 45W of power during operation.

Environmental Specifications

Designed for professional broadcast environments, the panel operates reliably in temperatures ranging from 0° to 40°C (32° to 104°F). For storage, it can withstand temperatures between -20° to 60°C (-4° to 140°F). It also supports relative humidity levels of up to 95% non-condensing, ensuring durability and stability in varying conditions.

What’s Included

The package includes the ATEM 1 M/E Advanced Panel 10 along with standard accessories for immediate setup.

Warranty

The product is backed by a 1-Year Limited Manufacturer’s Warranty, ensuring dependable support and protection.
